NCA 14SQ

The Pocket Rocket

Australian Built • NCA Designed • Backed by a 2-Year Warranty

The NCA 14SQ is the most compact high-performance single-handed racing catamaran in the NCA range — but don’t let its size fool you.

NCA 14SQ – THE POCKET ROCKET

The NCA 14SQ is the most compact high-performance single-handed racing catamaran in the NCA range — but don’t let its size fool you.

With rapid acceleration, high-lift daggerboards and its unique boomless outhaul traveller car system allowing precise sail-shape adjustment, the NCA 14SQ is capable of competing with much larger boats while remaining simple to rig, launch and sail.

Equally suited to sailors stepping into performance catamaran sailing or experienced racers looking for a lightweight, responsive and exciting racing machine.

NCA 14SQ - The Pocket Rocket

Why choose the NCA 14SQ?

Lightweight and easy to launch, rig and transport

Genuine high-performance single-handed racing catamaran

Unique boomless outhaul traveller car system for precise sail-shape control

Fast acceleration and excellent upwind performance

Australian designed, manufactured and supported

NCA 14SQ - The Pocket Rocket
NCA 14SQ - The Pocket Rocket
NCA 14SQ - The Pocket Rocket

Key Features

  • Moulded foam sandwich vinylester hulls with NPG gelcoat finish for lightweight strength and long-term durability
  • Boomless Flex Mylar square-top mainsail (IACTS) for modern high-performance sailing
  • Integrated adjustable clew traveller system for precise sail-shape control
  • Ackerman steering geometry for responsive and accurate handling
  • Carbon-reinforced rudders and daggerboards for strength and performance
  • Anodised aluminium spars and coated shrouds for corrosion resistance and long service life
  • Racing battens for improved sail shape and aerodynamic efficiency
  • Adjustable kick-up rudders for safe beach launching and retrieval
  • Quick-release rudder system for easy transport and storage
  • Single trapeze system for maximum racing performance and control
  • Captive ball mast-step system for safer mast raising and lowering
  • Aluminium tiller extension for lightweight and responsive steering
  • 6:1 mainsheet purchase system for smooth sail adjustment
  • 10:1 downhaul system for powerful sail-shape control
  • RCB traveller car system for precise mainsail trimming
  • Adjustable mast rotation controls for improved upwind and downwind performance
  • Round aluminium cross beams providing a strong and rigid platform
  • One-piece mesh trampoline with integrated storage pocket
  • High-lift daggerboard design for excellent upwind performance
  • Lightweight racing platform engineered for rapid acceleration
  • Australian-designed and manufactured using premium materials
  • Full factory parts and technical support available
  • Backed by a comprehensive 2-Year Limited Warranty

Specifications

Specification Value
Length: 4.50 m
Width: 2.44 m
Weight: 105 kg
Sail Area: 14 m²
Trapeze: Single
Construction: Foam Sandwich Vinylester
Designer: Ross Guinea / NCA Catamarans

Summary

Fast, modern, lightweight and incredibly fun, the NCA 14SQ delivers genuine racing performance in a compact and easy-to-manage package.

Whether you’re looking for your first performance catamaran or your next racing weapon, the NCA 14SQ offers speed, simplicity and excitement in equal measure.
